The types of high speed Steel 304L Slip-On Flanges and Stainless Steel 304L Forged Flanges available in the market are reducing flange and nipo flanges, etc. Ashtavinayaka Overseas are one of the leading traders, suppliers, exporters and dealers of Stainless Steel Flanges, Stainless Steel 304L Slip On Flanges, 304L SS Blind Flanges, Steel 304L Weld-Neck Flanges, SS 304L Flat Face and Threaded 304L Steel Flanges in Mumbai, India. The standard that we developed are ASTM, ASME, DIN norms. These Stainless 304L Blind Flange available in various forms of Flange come with dimensions shapes, grades, types and other details.
Their steel 304L Flange products material properties are good, making the product very sustainable and compatible. Ashtavinayaka Overseas is involved in offering a complete array of Stainless Steel 304L Plate Flange, Reducing FlangesRing Type Joint Flange, Square Flanges, Plate Flange, as a stockiest and supplier to our domestic and global clients. These SS 304L Welding Flange mostly used in Oil Gas Industry, Cement Industry, Chemical industry, pharma industry, power plant, paper industry, cement plant, etc.
| Products | Stainless Steel Flange, UNS S30403, WERKSTOFF NR. 1.4307 |
| Standard | ASTM A182 / ASME SA182 |
| Size | 1/2" (15 NB) to 48" (1200NB) / DN10~DN5000 |
| SS 304L Flanges Standards | BS 10, EN-1092, ASME Flange, BS Flange, DIN Flange, ANSI/ASME B16.5, DIN, ANSI Flange, BS4504, B16.47 Series A & B, B16.48, EN Flange, GOST Flange. |
| SS 304L Flanges Standard DIN | 6Bar 10Bar 16Bar 25Bar 40Bar, PN6 PN10 PN16 PN25 PN40, PN64 |
| SS 304L Flanges Standard ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| SS 304L Flanges Standard UNI | 10 Bar, 16 Bar, 6 Bar, 25 Bar, 40 Bar |
| SS 304L Industrial Flanges Standard JIS | 5K, 10 K, 30 K, 16 K 20 K, 40 K, 63 K |
| SS 304L Pipe Flanges Standard EN | 16Bar 25Bar 40Bar 6Bar 10Bar |
| Type | Blind Flange, Weld-Neck Flange, Small Tongue, Slip-On Flange, Small Male-Female (SMF), Large Tongue & Groove, Lap-Joint Face (LJF), Flat Face (FF), Raised Face (RF), Large Male-Female (LMF), Ring Type Joint (RTJ), Threaded Flange, Socket Weld Flange |
| Origin | European Origin, Korea Origin, US Origin, Japanese Origin, Indian Origin |
| S30403 SS 304L Lap-joint Flanges Dealer in india | 304L Stainless Steel Hot Rolled Flange |
| 2B Finish Stainless Steel 304L Flange Distributors in india | ASTM A182 Large Diameter 304L Lap joint Flange |
| 304L Stainless Steel Orifice Flange | 304L Steel Flange Stockholder in india |
| SS 304L Flange Suppliers in India | ASTM A182 Stainless Steel 304L Long Neck Flange |
| ASTM A182 Stainless 304L Flange | 1.4307 Steel 304L Flanges Dealers |
| 304L SS Slip On Flanges Dealers | 304L Stainless Steel Blind Flange |
| ASTM A182 Stainless Steel 304L Flange | A182 SS 304L Weld Neck Flange |
| 304L SS Threaded Flange Wholesaler in india | ASME SA182 Finish SS 304L Socket Weld Flange |
| UNS S30403 Stainless Steel 304L Flanges Supplier in india | SS 304L Spectacle Flange Distributors in india |
| UNS S30403 Stainless Steel 304L Flange Importers in india | A182 SS 304L Flange Suppliers in india |
| WERKSTOFF NR. 1.4307 SS 304L Flange Importers in Delhi | 304L SS Flat Face Flange Suppliers in india |
| Stainless Steel 304L Raised Face Flanges | 304L Stainless Steel Flange Manufacturer in Mumbai |
| Reducing Steel 304L Flange Manufacturers in india | ASTM A182 Stainless Steel 304L Ring Type Joint Flange |
| 304L SS Flange Dealers | 304L SS Square Flange Stockist in India |
| Stainless Steel 304L Nipo Flange | Steel 304L Reducing Flange in India |
| Stainless Steel 304L Forged Flange Suppliers | 304L Stainless Flange Suppliers Navi Mumbai |
| Steel 304L Flange Exporters in Mumbai | SS 304L Reducing Flange India |
| SS 304L High Pressure Fittings Flange | Stainless 304L Flange Stockist in india |
| Stainless Steel 304L Flange in India | 304L Stainless High Pressure Flange Traders in india |
| Stainless Steel 304L Pipe Flange | SS 304L Flange Stockholder in India |
| 304L Stainless Steel Blind Flange | 304L SS Flange Exporters |
| ASA / ANSI /ASME B16.34 | ANSI PRESSURE RATING CHART | ||||||
|---|---|---|---|---|---|---|---|
| °F Temperature | 150 LBS | 300 LBS | 400 LBS | 600 LBS | 900 LBS | 1500 LBS | 2500 LBS |
| -20 to 100 | 275 | 720 | 960 | 1440 | 2160 | 3600 | 6000 |
| 200 | 230 | 600 | 800 | 1200 | 1800 | 3000 | 5000 |
| 300 | 205 | 540 | 720 | 1080 | 1620 | 2700 | 4500 |
| 400 | 190 | 495 | 660 | 995 | 1490 | 2485 | 4140 |
| 500 | 170 | 465 | 620 | 930 | 1395 | 2330 | 3880 |
| 600 | 140 | 435 | 580 | 875 | 1310 | 2185 | 3640 |
| 650 | 125 | 430 | 575 | 860 | 1290 | 2150 | 3580 |
| 700 | 110 | 425 | 565 | 850 | 1275 | 2125 | 3540 |
| 750 | 95 | 415 | 555 | 830 | 1245 | 2075 | 3460 |
| 800 | 80 | 405 | 540 | 805 | 1210 | 2015 | 3360 |
| 850 | 65 | 395 | 530 | 790 | 1190 | 1980 | 3300 |
| 900 | 50 | 390 | 520 | 780 | 1165 | 1945 | 3240 |
| 950 | 35 | 380 | 510 | 765 | 1145 | 1910 | 3180 |
| 1000 | 20 | 320 | 430 | 640 | 965 | 1605 | 2675 |
| 1050 | 20 | 310 | 410 | 615 | 925 | 1545 | 2570 |
| 1100 | 20 | 255 | 345 | 515 | 770 | 1285 | 2145 |
| 1150 | 20 | 200 | 265 | 400 | 595 | 995 | 1655 |
| 1200 | 20 | 155 | 205 | 310 | 465 | 770 | 1285 |
| 1250 | 20 | 115 | 150 | 225 | 340 | 565 | 945 |
| 1300 | 20 | 85 | 115 | 170 | 255 | 430 | 715 |
| 1350 | 20 | 60 | 80 | 125 | 185 | 310 | 515 |
| 1400 | 20 | 50 | 65 | 95 | 145 | 240 | 400 |
| 1450 | 15 | 35 | 45 | 70 | 105 | 170 | 285 |
| 1500 | 10 | 25 | 35 | 55 | 80 | 135 | 230 |
| Pipe Normal Diameter (inch) | Outer diameter Flange | Thicjness Of Flange Minimum | Diameter of Hub |
Diameter of Raised Face | Length Hub.Y | Thread Length | Diameter of Bolt Circle |
Diameter of Bolt Holes |
Number of Bolts |
Diameter of Bolts (inch) |
KG | LB | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1/2" | 15 | 89.00 | 11.20 | 30.20 | 35.10 | 15.70 | 15.70 | 60.50 | 15.80 | 4 | 1/2" | 0.4 | 0.9 |
| 3/4" | 20 | 98.50 | 12.70 | 38.10 | 42.90 | 15.70 | 15.70 | 69.90 | 15.80 | 4 | 1/2" | 0.7 | 1.5 |
| 1" | 25 | 108.00 | 14.20 | 49.30 | 50.80 | 17.50 | 17.50 | 79.30 | 15.80 | 4 | 1/2" | 0.8 | 1.8 |
| 1-1/4" | 32 | 117.50 | 15.70 | 58.70 | 63.50 | 20.60 | 20.60 | 88.90 | 15.80 | 4 | 1/2" | 1.2 | 2.6 |
| 1-1/2" | 40 | 127.00 | 17.50 | 65.00 | 73.20 | 22.40 | 22.40 | 98.60 | 15.80 | 4 | 1/2" | 1.5 | 3.3 |
| 2" | 50 | 152.50 | 19.10 | 77.70 | 91.90 | 25.40 | 25.40 | 120.70 | 19.10 | 4 | 5/8" | 2.3 | 5.1 |
| 2-1/2" | 65 | 178.00 | 22.40 | 90.40 | 104.60 | 28.40 | 28.40 | 139.70 | 19.10 | 4 | 5/8" | 3.7 | 8.1 |
| 3" | 80 | 190.50 | 23.90 | 108.00 | 127.00 | 30.20 | 30.20 | 152.40 | 19.10 | 4 | 5/8" | 4.1 | 9 |
| 3-1/2" | 90 | 216.00 | 23.90 | 122.20 | 139.70 | 31.80 | 31.80 | 177.80 | 19.10 | 8 | 5/8" | 5.1 | 11.2 |
| 4" | 100 | 228.50 | 23.90 | 134.90 | 157.20 | 33.30 | 33.30 | 190.50 | 19.10 | 8 | 5/8" | 5.9 | 13 |
| 5" | 125 | 254.00 | 23.90 | 163.60 | 185.70 | 36.60 | 36.60 | 215.90 | 22.40 | 8 | 3/4" | 7 | 15.4 |
| 6" | 150 | 279.50 | 25.40 | 192.00 | 215.90 | 39.60 | 39.60 | 241.30 | 22.40 | 8 | 3/4" | 8.4 | 18.5 |
| 8" | 200 | 343.00 | 28.40 | 246.10 | 269.70 | 44.50 | 44.50 | 298.50 | 22.40 | 8 | 3/4" | 13 | 28.6 |
| 10" | 250 | 406.50 | 30.20 | 304L.80 | 323.90 | 49.30 | 49.30 | 362.00 | 25.40 | 12 | 7/8" | 18 | 39.5 |
| 12" | 300 | 482.50 | 31.80 | 365.30 | 381.00 | 55.60 | 55.60 | 431.80 | 25.40 | 12 | 7/8" | 29 | 64 |
| 14" | 350 | 533.50 | 35.10 | 400.10 | 412.80 | 57.20 | 57.20 | 476.30 | 28.50 | 12 | 1" | 39 | 86 |
| 16" | 400 | 597.00 | 36.60 | 457.20 | 469.90 | 63.50 | 63.50 | 539.80 | 28.50 | 16 | 1" | 47 | 103 |
| 18" | 450 | 635.00 | 39.60 | 505.00 | 533.40 | 68.30 | 68.30 | 577.90 | 31.80 | 16 | 1 1/8" | 57 | 126 |
| 20" | 500 | 698.50 | 42.90 | 558.80 | 584.20 | 73.20 | 73.20 | 635.00 | 31.80 | 20 | 1 1/8" | 76 | 167 |
| 24" | 600 | 813.00 | 47.80 | 663.40 | 692.20 | 82.60 | 82.60 | 749.30 | 35.10 | 20 | 1 1/4" | 97 | 214 |
| STANDARD | WERKSTOFF NR. | UNS | GOST | JIS | BS | AFNOR | EN |
| SS 304L | 1.4307 | S30403 | 03Х18Н11 | SUS 304L | 304S11 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 |
| Grade | Mn | S | P | Cr | Si | C | Ni |
| SS 304L | 2.0 max | 0.03 max | 0.045 max | 18 - 20 | 1.0 max | 0.035 max | 8 - 13 |
| Density | Yield Strength (0.2%Offset) | Tensile Strength | Melting Point | Elongation |
| 8.0 g/cm3 | Psi - 30000 , MPa - 205 | Psi - 75000 , MPa - 515 | 1400 °C (2550 °F) | 35 % |
Latest Prices for Stainless Steel 304L Blind Flange Price and SS 304L Weld Neck Flange Products are very reasonable. 304L SS Threaded Flange Prices, Stainless Steel 304L Socket Weld Flanges Latest Price List Ashtavinayaka Overseas SS 304L Flange Best Price at the wholesale price in Mumbai, Maharashtra, India.
